Jumbo adjustable combined bearing
4.039
Drawing-controlled 185 mm class combined bearing for heavy industrial guide and handling systems.
Cross-reference note: WINKEL and other manufacturer designations are used for buyer identification. We manufacture compatible bearings to the confirmed drawing unless an original branded product is expressly quoted.
Specifications
4.039 technical data
| D | 185 mm class from reference |
|---|---|
| H | 95 mm reference |
| Execution | Drawing-based custom combined bearing |
| RemainingDimensions | Confirm controlled drawing |
| LoadRatings | Not published |
Selection notice: Dimensions and catalog ratings are factory reference data. Verify the controlled drawing during quotation.
4.039 cross references
Common purchasing and maintenance references include 4.039 · JD185-95 · 4.039 custom combined bearing.
Suffixes, seals, lubrication, OD variants and mounting plates can change fit. Send the complete marking and a controlled drawing for confirmation.
Execution guidance
Jumbo adjustable design and inspection
Design function
Jumbo models provide a larger radial roller and an adjustable axial arrangement for severe-duty guides.
Installation and adjustment
Confirm the adjustment method, locking arrangement and structural clearance before setting the guide.
Inspection focus
Check eccentric or axial adjustment travel, mounting interfaces, load surfaces and lubrication access.
Application
Application and RFQ checklist
Metallurgical equipment, conveyors, lifting systems, logistics equipment and heavy linear guides.
Information required for selection
- Dimensions
- d, D, H, B, S, T and plate or stud geometry
- Load
- Radial load, axial load, shock, speed and duty cycle
- Execution
- Standard, precision, fixed axial or eccentric-adjustable
- Environment
- Temperature, contamination, sealing and lubrication
