Welded plate combined bearing
AP92-Q
AP92-Q plate assembly with a 4.092 jumbo eccentric-adjustable combined bearing for severe-duty guides.
Cross-reference note: WINKEL and other manufacturer designations are used for buyer identification. We manufacture compatible bearings to the confirmed drawing unless an original branded product is expressly quoted.
Specifications
AP92-Q technical data
| d | 120 mm |
|---|---|
| D | 250 mm |
| H | 102 mm |
| Hmax | 105 mm |
| h | 77-80 mm |
| B | 60 mm |
| S | 75 mm |
| T | 168 mm |
| A | 7-10 mm |
| r | 5 mm |
| FR | 101.5 kN |
| FA | 33.9 kN |
| Cr | 369 kN |
| C0r | 748 kN |
| Ca | 138 kN |
| C0a | 257 kN |
| Speed | 75 rpm |
| Mass | 23.9 kg |
| Assembly | 4.092 on AP92-Q plate |
Selection notice: Dimensions and catalog ratings are factory reference data. Verify the controlled drawing during quotation.
AP92-Q cross references
Common purchasing and maintenance references include AP92-Q · JD250-102-KPD · 400-0092 · MR0014 · 4.092 AP92-Q.
Suffixes, seals, lubrication, OD variants and mounting plates can change fit. Send the complete marking and a controlled drawing for confirmation.
Execution guidance
Welded plate design and inspection
Design function
The bearing is supplied with a welded mounting plate for direct integration into the guide structure.
Installation and adjustment
Plate hole pattern, weld orientation and datum position must match the complete AP drawing.
Inspection focus
Inspect plate flatness, hole spacing, weld condition, bearing position and marking.
Application
Application and RFQ checklist
Large mast systems, steel equipment, cranes and heavy adjustable linear guide structures.
Information required for selection
- Dimensions
- d, D, H, B, S, T and plate or stud geometry
- Load
- Radial load, axial load, shock, speed and duty cycle
- Execution
- Standard, precision, fixed axial or eccentric-adjustable
- Environment
- Temperature, contamination, sealing and lubrication
